LCD Display Plus Circuit Board Assembly 2052116 for Asphalt Paver Sidebox Panel

The 2052116 assembly is the LCD display and circuit board module fitted to the sidebox control panel of asphalt pavers. It is supplied as a complete, ready-to-fit unit: the LCD screen and its control board are already mounted together, so a fault in the display does not require separating the screen from the electronics or matching a bare panel to an existing board.

The module is the interface operators use throughout a shift. Grade and slope values, travel speed, screed settings and function status all pass through this display, which means a failing unit affects paving accuracy directly rather than just convenience.

• Faded or partial readouts. Segments, digits or backlight missing on part of the screen while the machine otherwise runs normally.
• No display with power present. Backlight dark and no characters, but the panel responds when buttons are pressed.
• Scrambled values. Grade or speed readings jumping, freezing, or showing dashes that do not correspond to machine state.
• Intermittent dropouts in heat. Screen cutting out after hours of working temperature, then recovering when the machine cools.
• Unresponsive buttons with a live screen. Indicates a board-level fault rather than a panel or harness problem.

Before ordering, check the harness connector and panel supply voltage. A loose connector or low supply produces symptoms that look identical to a failed display.

• Switch off the machine and isolate the electrical system before opening the sidebox panel.
• Photograph the harness routing and connector positions before removal for reference during refitting.
• Check connector pins for corrosion or backing out; a poor connection will repeat the original fault.
• Fit the module without forcing the connector, then confirm the display initialises before closing the panel.
• Verify grade and slope readings against a known reference after installation, before paving resumes.

Supply capacity is 1,000 pieces per year, with single-piece orders accepted and delivery in 3-10 days after payment. Payment is accepted by T/T or L/C, and units ship in cartons or boxes with protective packing for the display face.

Send the part number 2052116, the machine model and the quantity required, and we will confirm stock, freight cost and shipment date on the same working day.
